Application
|
Cat.5
|
|
Application area
|
- Installation
- Mobile outdoor / indoor
- Studio / Broadcast
|
|
AWG (network)
|
26
|
|
BPVo-Euroclass
|
Fca
|
|
Capacity wire/wire at 1m (network)
|
48 pF
|
|
CAT-Type
|
CAT.5
|
|
Colour
|
black
|
|
Colour detailed
|
black
|
|
Conductor insulation material
|
Foam/Skin-PE
|
|
Construction (network)
|
SFTP 4x2x0,15mm²
|
|
Copper strand Ø (network)
|
0,10 mm
|
|
Copper strands (network)
|
19
|
|
Farge
|
Sort
|
|
Fire load per m
|
0,11 kWh
|
|
Height
|
6,2 mm
|
|
Impedance
|
100 Ohm
|
|
Inner conductor (network)
|
8
|
|
Insulation resist. per 1 km
|
5 G Ohm
|
|
Insulation resist. per 1 km (network)
|
5 G Ohm
|
|
Jacket material
|
PUR-FRNC
|
|
Jacket Ø
|
6,2 mm
|
|
Loop resistance per km
|
142 Ohm
|
|
Materiale
|
PUR-FRNC
|
|
Max. section length
|
65 m
|
|
Packing
|
|
|
Properties
|
- Digital 110 Ohm AES / EBU
- FRNC flame retardant
- Halogen-free / LSZH
- OFC oxygen free copper
- PUR
|
|
Shielding
|
AL / PT-foil + copper braiding 90 % tin-plated
|
|
Shielding factor
|
1
|
|
Style variant
|
round
|
|
Temperature max.
|
70 °C
|
|
Temperature min.
|
-15 °C
|
|
UV-resistant
|
Yes
|
|
Velocity factor
|
0,73
|
|
Weight per 1 m
|
53 g
|
|
Width
|
6,2 mm
|
