Application
|
BUS Control cable
|
|
Application area
|
- ELA 100 V
- Installation
- Mobile outdoor / indoor
- Studio / Broadcast
|
|
AWG (audio)
|
21
|
|
AWG (power)
|
14
|
|
Capac. cond./cond. per 1 m (audio)
|
65 pF
|
|
Capac. cond./shield. per 1 m (audio)
|
104 pF
|
|
Colour
|
black
|
|
Colour detailed
|
black
|
|
Conductor insulation Ø (audio)
|
1,3 mm
|
|
Conductor resistance per 1 km (audio)
|
60 Ohm
|
|
Copper strand Ø (audio)
|
0,10 mm
|
|
Copper strands (audio)
|
45
|
|
Farge
|
Sort
|
|
Fire load per m
|
0,32 kWh
|
|
Height
|
7,4 mm
|
|
Inner conductor (audio)
|
|
|
Inner conductor (power)
|
|
|
Inner conductor Ø (audio)
|
0,67 mm
|
|
Inner conductor Ø (power)
|
1,6 mm
|
|
Jacket material
|
FRNC
|
|
Jacket Ø
|
7,4 mm
|
|
Jacket Ø (audio)
|
2,5 mm
|
|
Materiale
|
FRNC
|
|
Number of Channels (power)
|
1
|
|
Packing
|
bulk stock
|
|
Properties
|
- Analog
- Digital 110 Ohm AES / EBU
- OFC oxygen free copper
|
|
Shield. resistance per 1 km
|
25 Ohm
|
|
Shielding (audio)
|
AL / PT foil + filler strand
|
|
Shielding factor
|
1
|
|
Signal transmission
|
symmetrical
|
|
Style variant
|
round
|
|
Surge impedance (audio)
|
110 Ohm
|
|
Temperature max.
|
70 °C
|
|
Temperature min.
|
-25 °C
|
|
Type
|
Høyttalerkabel
|
|
UV-resistant
|
Yes
|
|
Weight per 1 m
|
88 g
|
|
Width
|
7,4 mm
|
|
Wire insulation material (audio)
|
PP
|
