Application
|
- Installation cable
- Speaker Cable
|
|
Application area
|
- ELA 100 V
- Installation
- Studio / Broadcast
|
|
AWG (audio)
|
10
|
|
BPVo-Euroclass
|
Fca
|
|
Capac. cond./cond. per 1 m (audio)
|
125 pF
|
|
Colour
|
grey
|
|
Colour detailed
|
dark grey
|
|
Conductor insulation Ø
|
4,7 mm
|
|
Conductor resistance per 1 km
|
3,3 Ohm
|
|
Copper strand Ø (audio)
|
0,3 mm
|
|
Copper strands (audio)
|
84
|
|
Farge
|
Grå
|
|
Fire load per m
|
0,81 kWh
|
|
Height
|
11,2 mm
|
|
Inner conductor (audio)
|
6 mm²
|
|
Inner conductor Ø (audio)
|
2,76 mm
|
|
Insulation resist. per 1 km
|
0,005 G Ohm
|
|
Insulation resist. per 1 km (audio)
|
0,005 G Ohm
|
|
Jacket material
|
FRNC
|
|
Jacket Ø
|
11,2 mm
|
|
Number of Channels (audio)
|
1
|
|
Packing
|
|
|
Properties
|
- Analog
- FRNC flame retardant
- Halogen-free / LSZH
- OFC oxygen free copper
|
|
Style variant
|
round
|
|
Temperature max.
|
70 °C
|
|
Temperature min.
|
-30 °C
|
|
Tverrsnitt
|
2 x 6.0 mm²
|
|
Weight per 1 m
|
226 g
|
|
Width
|
11,2 mm
|
