Application
|
Speaker Cable
|
|
Application area
|
- ELA 100 V
- Installation
- Studio / Broadcast
|
|
BPVo-Euroclass
|
Fca
|
|
Capac. cond./cond. per 1 m (audio)
|
140 pF
|
|
Colour
|
black
|
|
Colour detailed
|
black
|
|
Conductor resistance per 1 km
|
5 Ohm
|
|
Copper strand Ø (audio)
|
0,15 mm
|
|
Copper strands (audio)
|
225
|
|
Fire load per m
|
0,32 kWh
|
|
Height
|
8 mm
|
|
Inner conductor (audio)
|
|
|
Inner conductor Ø (audio)
|
2,26 mm
|
|
Insulation resist. per 1 km
|
0,2 G Ohm
|
|
Insulation resist. per 1 km (audio)
|
0,2 G Ohm
|
|
Jacket material
|
PVC
|
|
Jacket Ø
|
8 mm
|
|
Materiale
|
PVC
|
|
Number of Channels (audio)
|
1
|
|
Packing
|
|
|
Properties
|
- Analog
- OFC oxygen free copper
|
|
Shield. resistance per 1 km
|
5,5 Ohm
|
|
Shielding
|
Double copper spiral, counter-rotating
|
|
Shielding factor
|
1
|
|
Style variant
|
round
|
|
Temperature max.
|
70 °C
|
|
Temperature min.
|
-25 °C
|
|
Tverrsnitt
|
2 x 4.0 mm²
|
|
Type
|
Høyttalerkabel
|
|
UV-resistant
|
Yes
|
|
Weight per 1 m
|
135 g
|
|
Width
|
8 mm
|
