Application
|
Speaker Cable
|
Application area
|
- ELA 100 V
- Installation
- Studio / Broadcast
|
AWG (audio)
|
13
|
BPVo-Euroclass
|
Fca
|
Capac. cond./cond. per 1 m (audio)
|
150 pF
|
Colour
|
black
|
Colour detailed
|
black
|
Conductor resistance per 1 km
|
7,8 Ohm
|
Copper strand Ø (audio)
|
0,15 mm
|
Copper strands (audio)
|
140
|
Fire load per m
|
0,18 kWh
|
Height
|
6 mm
|
Inner conductor (audio)
|
2
|
Inner conductor Ø (audio)
|
1,78 mm
|
Insulation resist. per 1 km
|
0,2 G Ohm
|
Insulation resist. per 1 km (audio)
|
0,2 G Ohm
|
Jacket material
|
FRNC
|
Jacket Ø
|
6 mm
|
Materiale
|
FRNC
|
Number of Channels (audio)
|
1
|
Packing
|
|
Properties
|
- Analog
- FRNC flame retardant
- Halogen-free / LSZH
- OFC oxygen free copper
|
Shield. resistance per 1 km
|
9 Ohm
|
Shielding
|
Double copper spiral, counter-rotating
|
Shielding factor
|
1
|
Style variant
|
round
|
Temperature max.
|
70 °C
|
Temperature min.
|
-25 °C
|
Tverrsnitt
|
2 x 2.5 mm²
|
Type
|
Høyttalerkabel
|
UV-resistant
|
Yes
|
Weight per 1 m
|
73 g
|
Width
|
6 mm
|
