Application
|
- Installation cable
- Speaker Cable
|
|
Application area
|
- ELA 100 V
- Installation
- Studio / Broadcast
|
|
AWG (audio)
|
16
|
|
BPVo-Euroclass
|
Fca
|
|
Capac. cond./cond. per 1 m (audio)
|
150 pF
|
|
Colour
|
black
|
|
Colour detailed
|
black
|
|
Conductor insulation Ø
|
2,62 mm
|
|
Conductor resistance per 1 km
|
13 Ohm
|
|
Copper strand Ø (audio)
|
0,15 mm
|
|
Copper strands (audio)
|
84
|
|
Farge
|
Sort
|
|
Fire load per m
|
0,29 kWh
|
|
Height
|
6,8 mm
|
|
Inner conductor (audio)
|
1,5 mm²
|
|
Inner conductor Ø (audio)
|
1,38 mm
|
|
Insulation resist. per 1 km
|
0,005 G Ohm
|
|
Insulation resist. per 1 km (audio)
|
0,005 G Ohm
|
|
Jacket material
|
FRNC
|
|
Jacket Ø
|
6,8 mm
|
|
Number of Channels (audio)
|
1
|
|
Packing
|
|
|
Properties
|
- Analog
- FRNC flame retardant
- Halogen-free / LSZH
- OFC oxygen free copper
|
|
Style variant
|
round
|
|
Temperature max.
|
70 °C
|
|
Temperature min.
|
-30 °C
|
|
Tverrsnitt
|
2 x 1.5 mm²
|
|
UV-resistant
|
Yes
|
|
Weight per 1 m
|
78 g
|
|
Width
|
6,8 mm
|
