CONTROL FLEX  4x0,50mm² grå Control lead SC-Control Flex

CONTROL FLEX 4x0,50mm² grå

Control lead SC-Control Flex

Varenr: 380-0056-04050
31,-eks. mva
Logg inn for å se dine nettopriser.
Ikke kunde? Søk om kundestatus.
-+
100+ på lager
BeskrivelseTeknisk infoSupport
Beskrivelse

Paying the taxman...

and controlling them yourself with the control device. That would be the ticket! We deliver a robust and yet very flexible control cable which serves as a signal line in the milliampere range for control devices (e.g. RS232 and RS422) and computer systems. The special jacket is self-extinguishing and flame-retardant pursuant to VDE 0472, part 804/test type B (in accordance with DIN EN 60332-1-1/IEC 60332-1). The SC-Control Flex is rounded out by a braided Cu shielding (opt. coverage > 90 %) which makes it particularly suitable for EMC-problematic applications.

Advantages:

  • Available from stock in seven different wire gauges
  • Remains flexible in moving conditions down to –10 °C (fixed installation -30 °C)
  • Largely oil-resistant
  • Self-extinguishing and flame-retardant in compliance with VDE 0472, Part 804, test type B
  • Very easy handling

Application:

  • Fixed installation in building technology
  • Signal line, control engineering
  • Transmission of the RS232 and RS422 standards
  • Speaker Cable for ELA technology
Teknisk info

Produktinformasjon

Farge Grå
Ledere 4
