PRIMUS Microphonc. / sort Optimal overføringskvalitet.

PRIMUS Microphonc. / sort

Optimal overføringskvalitet.

Varenr: 200-0151
27,-eks. mva
Logg inn for å se dine nettopriser.
Ikke kunde? Søk om kundestatus.
FargeSort
PRIMUS Microphonc. / sort Optimal overføringskvalitet.
PRIMUS Microphonc. / blå Optimal overføringskvalitet.
Materiale
Vis varianter som liste
-+
ikke på lager (13 dager)
BeskrivelseTeknisk infoSupport
Beskrivelse

The marathon runner...

Will have a hard time and must run. Likewise our cables must cover the long distances at the sports arena. But they will lie and not run. So due to its cross-section 2 x 0,50 mm², this cable is also ideal for theaters, public buildings, etc. Owing to the 100 % shielding and the thick outer jacket, the SC-Primus is also recommended for installations at discotheques, because neither the aggressive nicotine nor wild temperature fluctuations can hardly do any harm to this cable. Gigging musicians swear by this cable, rental shop owners prefer the SC-Primus because of its durability and a slight bounce, making manual winding easy.

Advantages:

  • Optimum transmission quality even with excess lengths due to the large wire gauge of 2 x 0,50 mm²
  • 100 % shielding due to dense helical copper mesh screen and extra metallised fleece
  • Great durability due to the thick PVC with a diameter of 6,70 mm
  • Easy to reel and good tensile strength

Application:

  • Broadcasting and OB van technology, building installation
  • Professional studio technology
  • Tough stage application
  • Installation in discos, coffee shops, at sporting events
Teknisk info

Produktinformasjon

Application Microphone Cable
Application area
  • ELA 100 V
  • Installation
  • Mobile outdoor / indoor
  • Stage / live
  • Studio / Broadcast
AWG (audio) 20
BPVo-Euroclass Fca
Capac. cond./cond. per 1 m (audio) 80 pF
Capac. cond./shield. per 1 m (audio) 145 pF
Colour black
Colour detailed black
Conductor insulation material PE
Conductor insulation Ø 1,65 mm
Conductor resistance per 1 km 37 Ohm
Copper strand Ø (audio) 0,15 mm
Copper strands (audio) 28
Farge Sort
Fire load per m 0,23 kWh
Height 6,5 mm
Inner conductor (audio) 0,50 mm²
Inner conductor Ø (audio) 0,80 mm
Insulation resist. per 1 km 1 G Ohm
Insulation resist. per 1 km (audio) 1 G Ohm
Jacket material PVC
Jacket Ø 6,5 mm
Materiale PVC
Number of Channels (audio) 1
Packing
  • 100 m spool
  • 500 m spool
Properties
  • Analog
  • OFC oxygen free copper
Shield. resistance per 1 km 27 Ohm
Shielding Copper spiral sleeve tin-plated + metalic fleece
Shielding factor 1
Signal transmission symmetrical
Style variant round
Temperature max. 70 °C
Temperature min. -25 °C
Type Mikrofonkabel
UV-resistant Yes
Weight per 1 m 53 g
Width 6,5 mm
