TRUMPF is a curtain track for medium duty applications such as curtains and lightweight scenery. Curved track layouts are easily manufactured. TRUMPF shares many components, including runners with the TRUMPF 95 and STUDIO / E systems.
Technical Data
- Weight: 660 g/m (7.0 oz/ft)
- Length of Section: 6.00 m (19'8")
- Distance Between Hanging Points: 2.00 m (6'7")
- Min. Curve Radius: 0.30 m (11.8")
Safe Working Load
- Master Runner: 20 kg (44 lbs)
- 2-Wheel Runner: 10 kg (22 lbs)
- 4-Wheel Runner: 20 kg (44 lbs)
